  ATEX Vortex Flow Meter

  USD $2,007 – USD $8,800Price range: USD $2,007 through USD $8,800

  The Vortex flow meter is perfectly suited for measuring the flow, pressure and temperature of gases and steam. Ideal for use in steam, wet gas and on the outlet of compressors. Optional ATEx rating for use in explosive areas.

  Flow Range: 1.5 to 300 Nm/sec (5 to 931 ft/sec)

  Pipe Sizes: DN15 to DN300

  Accuracy: ±1.5% reading, ±0.3% full scale

  Output: Modbus (RS485) and 4-20mA

  Power Requirement: 18 to 30VDC / 10W@24V

  ATEx Rating: Optional

  Application
  • Steam, compressed air and gas
  • Compressor outlets
  • Manufacturing, industrial and pharmaceutical use
  • Temporary or permanent installation

  Select options
•

  ATEx

  ATEx Inline Flow Meter – IP67

  USD $1,821 – USD $4,143Price range: USD $1,821 through USD $4,143

  ATEX rated thermal mass flow meter suitable for clean, dry gas. Ideal for harsh environments or outdoor installations. Measure flow, mass flow, consumption and gas temperature.

  Flow Range: 0.1 to 250 Nm/s (0.3 to 820 ft/sec)

  IP Rating: IP67

  ATEx Rating: Optional

  Pipe Sizes: DN20 to DN300

  Accuracy: ±1.5% reading, ±0.3% full scale

  Output: Modbus (RS485) and 4-20mA

  Power Requirement: 18 to 30VDC / 5W@24VDC

  Applications
  • Outdoors or harsh environments
  • Clean and dry compressed air and inert gases
  • Manufacturing, industrial and pharmaceutical use
  • Temporary or permanent installation
